ZHD-7728 Hi-Lok® Installation Mini-Ratchet
Tool Advantages:
AThe right air ratchet for your Hi-Lok® installation for the quality seeking airframe mechanic.
- 1/4″ adapter that stays attached to the tool.
(With a special designed cap).
- Adjustable throttle to control the tool speed.
- ‘No-mar’ rubber protection.
- Thru-hole to be used with HEX key.
- Friction ring mechanism to keep the socket on the drive.
- Hi-Lok® Capacity up to – 1/4″ in Al, 3/16″ in Stainless Steel.
Specification:
- Free Speed: 400 rpm
- Max. Torque: 35(47.5) ft-lb(Nm)
- Avg. Air Cons.: 3(85) cfm(l/min)
- Air Inlet Size: 1/4 inch
- Net Weight: 1.06(0.48) lbs(kgs)
- Overall Length: 6-17/64(159) inch(mm)
- Min. Hose Size: 3/8(10) inch(mm)
- Operating Air Pressure: 90(6.2) PSI(kg/cm2)
| Model | Square Drive inch(mm) | Std Bolt Size inch(mm) | Free Speed rpm | Max. Torque ft-lb(Nm) | Avg. Air Cons. cfm(l/min) | Air Inlet Size inch | Net Weight lbs(kgs) | Overall Length inch(mm) | Min Hose Size inch(mm) |
| ZHD-7728 | – | – | 400 | 35(47.5) | 3(85) | 1/4 | 1.06(0.48) | 6-17/64(159) | 3/8(10) |
| ZP161 | 1/2(12.7) | 1/4(6.4) | 175 | 50(68) | 3(85) | 1/4 | 2.6(1.18) | 10-13/32(265) | 3/8(10) |
| ZP163 | 3/8(10) | 1/4(6.4) | 175 | 50(68) | 3(85) | 1/4 | 2.6(1.18) | 10-13/32(265) | 3/8(10) |
| ZP168 | 1/4(6.4) | 1/4(6.4) | 260 | 20(27) | 2.5(70) | 1/4 | 0.99(0.45) | 5-1/4(133) | 1/4(6.4) |
| ZP169 | 3/8(10) | 1/4(6.4) | 260 | 20(27) | 2.5(70) | 1/4 | 0.99(0.45) | 5-1/4(133) | 1/4(6.4) |
Recommended Gauge Air Pressure: 60~90psi
